    30W Water Cooling Laser Peeling Machine Very Fine Enamel Wire Stripping Machine

    Ask Lasest Price
    Brand Name : Leadboom
    Model Number : LB-CS30
    Certification : CE FDA
    Price : USD8800-22000/set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100sets/month
    Delivery Time : 7-10 work days
    • Product Details
    • Company Profile

    30W Water Cooling Laser Peeling Machine Very Fine Enamel Wire Stripping Machine

    30W Water Cooling New Laser Peeling Machine For Very Fine Enameled Wire


    Product Overview


    LB-CS Laser Stripping(peeling) Machine is professional designed for stripping three-layer insulated wires in transformer industries, with good results, fast speed, stable performance, to meet the needs for long time production.


    Technical Parameters


    ModelLB-CS30LB-CS100
    Laser Power0~30w0~100w
    Laser wavelength10640nm10640nm
    Pulse frequency≤50kHZ≤50kHZ
    Stripping scope110×110mm /140×140mm

    210×210mm/300×300mm

    Speed

    ≤7000mm/s≤7000mm/s

    minimum line width

    0.05mm0.06mm
    Repeated precision±0.003mm±0.003mm
    Cooling systemwater-cooled
    Power supplyAC220V/50HZAC220V/50HZ
    power consumption≤0.8KW≤3.0KW
    Dimension860mm×620mm×1360mm

    1400mm×650mm×1700mm


    Technical Features


    1. The core components adopted USA imported RF metal laser source, with long service life, the cavity always can be used.

    2. Stripping with high precision, PIN feet stripping can be finished in one time within working area, no damage on conductors.

    3. Stripping with fast speed, it only takes 0.2s for each Pin, can be equipped with automatic production line.

    4. Immersing tin with fast speed after stripping, it can prevent materials damages from long time immersing tin with high temperature..

    5. High electro-optical conversion efficiency, the whole power consumption is less then 800W, without consumable costs,low carbon and environmental protection.

    6. Controlled by computer, professional stripping control software that stripping shape, position,size, power, speed can be set freely, also can operate with multiple drawings.

    7. The equipment can be widely used in different materials, also can strip on and electronic wires.

    8. Professional low noise and strong smoke exhausting device is optional.

    Product Sample
    30W Water Cooling Laser Peeling Machine Very Fine Enamel Wire Stripping Machine
