    Low / High - Frequency Transformer Laser Stripping Machine Water - Cooled

    Ask Lasest Price
    Brand Name : Leadboom
    Model Number : LB-CS
    Certification : CE
    Price : 8000 USD/ set
    Payment Terms : L/C, T/T
    Supply Ability : 100000 set/year
    Delivery Time : 7 work day
    • Product Details
    • Company Profile

    Low / High - Frequency Transformer Laser Stripping Machine Water - Cooled

    High-frequency transformer Laser Stripping machine


    Product Overview

    LB-CS Laser Stripping(peeling) Machine is professionally designed for stripping three-layer insulated wires in transformer

    industries, with good results, fast speed, stable performance, to meet the needs for long time production.


    ModelLB-CS30LB-CS60LB-CS100
    Laser Power0~30w0~60w0~100w
    Laser wavelength10640nm10640nm10640nm
    Pulse frequency≤50kHZ≤50kHZ≤50kHZ
    Stripping scope110×110mm /140×140mm

    175×175mm

    /210×210mm

    210×210mm

    /300×300mm

    Speed


    ≤7000mm/s≤7000mm/s≤7000mm/s

    minimum

    line width

    0.05mm0.06mm0.06mm
    Repeated precision±0.003mm±0.003mm±0.003mm
    Cooling systemwater-cooled
    Power supplyAC220V/50HZAC220V/50HZAC220V/50HZ
    power consumption≤0.8KW≤2.0KW≤3.0KW
    Dimension860mm×620mm×1360mm

    1200mm×620mm×

    1500mm

    1400mm×650mm×

    1700mm



    Technical Features

    1. The core components adopted USA imported RF metal laser source, with long service life, the cavity always can be used.

    2. Stripping with high precision, PIN feet stripping can be finished in one time within working area, no damage on conductors.

    3. Stripping with fast speed, it only takes 0.2s for each Pin, can be equipped with automatic production line.

    4. Immersing tin with fast speed after stripping, it can prevent materials damages from long time immersing tin with high temperature.

    5. High electro-optical conversion efficiency, the whole power consumption is less then 800W, without consumable costs,low carbon and

    environmental protection.

    6. Controlled by computer, professional stripping control software that stripping shape, position,size, power, speed can be set freely, also can

    operate with multiple drawings.

    7. The equipment can be widely used in different materials, also can strip on and electronic wires.

    8. Professional low noise and strong smoke exhausting device is optional.


    Product application

    Three-layer insulating wires, wire, Electronic wires in transformer industries.
