    Fine Laser Beam Fiber Laser Marking Machine 20W For Communication Products

    Ask Lasest Price
    Brand Name : Raycus Laser
    Model Number : LB-MF20
    Certification : CE
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 30 sets per month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Fine Laser Beam Fiber Laser Marking Machine 20W For Communication Products



    HDMI Cable Fiber Laser Marking Machine Car Charger Adapter USB Cable Power Bank

    Machine Profile

    Fiber Laser Marking Machine adopted original fiber laser source and high speed galvanometer scanning system with stable power, excellent optical mode, beam with high quality, fast marking speed, good effects and high efficiency, it can meet the demand for mass production.

    Machine Features

    1 power controlled by software can be adjusted.

    2 Impored RF metal tube, with whole life use

    3 Large marking scope, the mark is clear and not easily destroyed.

    4 fast working speed and consistent performance

    Technical Parameters

    ModelMF10MF20MF30
    Laser Power10W20W30W
    Q-frequency20KHz ~ 30KHz
    Divergence0.3mard
    Marking Range100 X 100mm
    Minimum Line Width0.02mm
    Minimum Character0.15mm
    Marking Depth0 ~ 0.5mm
    Engraving Line Speed7000mm/s
    Repeatability Accuracy±0.001mm
    Beam QualityM2:1.2~1.8
    Marking FormatGraphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date,Batch Number,Serial Number,Frequency,etc.
    Graphic Format Supportedbmp, jpg, gif, tga, png, tif, ai, dxf, dst, plt, etc.
    Working Voltage220V±10%/50Hz/4A
    Unit Power<0.5kw
    Working Condition:Humidity5%-75%,Free of Condensed Water




    Standard Accessories (Fiber Laser Marking Machine)
    (1) A set of 20W Fiber Laser Device (Raycus) / 30W IPG Fiber Laser
    (2) A set of Scanning System (Galvotech)
    (3) A set of high-speed Scan Lens (Singapore Ronar-Smith)
    (4) 110mm x110mm Fiber Focus Lens (Singapore Ronar-Smith)
    (5) A set of Laser Beam Expanders (Singapore Ronar-Smith)
    (6) Motion control card
    (7) A set of marking control system
    (8) A set of marking software
    (9) An industrial computer
    (10) A red laser pointer
    (11) A pedal switch
    (12) Working table(300mmX300mm)
    (13) Laser power supply

    Application Fields

    Industry: plastic keypad, components of digital products, electronic components, electrical appliances, jewellery, precision machinery, hardware accessories, glasses, clocks and watches, vehicle and motor accessories, sanitary ware, communication products, medical devices, integrated circuit(IC), building material, pipe materials, more suitable for the marks of high demand of accuracy, speed and depth.

    Materials: metal and various nonmetal materials, high hardness alloy steel, oxide, electroplating and vacuum plating, epoxy resin, printing ink, ABS and other engineering plastic.
