Enameled wire laser peeling machine

Machine Profile

Enameled fiber laser stripping machine adopted with advanced CO2 RF laser device and high stale laser power and equipped with high-quality optical elements, automatic control system driver and high-speed scanning galvanometer system.

Free sample printing service is offered.

1. Parameters

Model: Dafeng-LCM10/30/50

Laser Power :10W/30w/50w

Laser wavelength 1064nm

Repeating Frequency ≤20KHZ

Beam Quality(m²) <2

Marking Range 100x100mm,200mm*200mm, 300mm*300mm(Optional)

Marking Speed ≤7000mm/s

Min.line Width 0.1-2mm

Min.Character 0.4mm

Repeatability Accuracy ±0.01mm

Power Supply 220V / 50Hz

Power Consumption 1.2kW

Dimension(LxWXH) 1000mm x 600mm x 1500mm

Weight ≤120kg

Operating System Win98/Win2000/WinXP/Win 7

Cooling Way Built-in air cooling

Control Interface Standard USB

File Format PLT,PCW,DXF,BMP,SHX,TTF etc.

Laser Type Pulse

2. Features:

1. Advanced closed rf CO2 laser;

2. Taiwan Mingwei laser power supply;

3. Double red light autofocus system;

4. Red light indicator system for outline, size, location, direction;

5. Imported wavelength whole series lens group;

6. Germany imported motor combination vibrating mirror;

7. The latest MQ6.0 flying marking control card;

8. Embedded touchscreen marking system;

9. Special lifting mobile station;

10. All-in-one air cooling;Keyence photoelectric;Omron differential encoding machine

3. Application

Applied in electronic components, integrated circuit (IC), electrical appliances, mobile communications, hardware, tools, accessories, precision instruments clocks and watches, glasses, jewelry accessories, auto parts, plastic buttons, building materials, PVC pipe, medical equipment and other industries.

Applicable materials include: ordinary metals and alloys (iron, copper, aluminum, magnesium, zinc, etc) all metal, rare metal and alloy (gold, silver, titanium), metal oxide (either all kinds of metal oxide), special surface treatment (phosphating, anodized aluminum, plating surface), ABS material (electrical appliances shell, daily necessities), ink (pervious to light buttons, printing products), epoxy resin (encapsulation of electronic components, insulating layer) bearing/chip/faucet/ring/frames/piston ring/handicraft/souvenirs/mobile phone key-press/clock/stainless steel tableware/drilling/carbide tools/stainless steel vacuum cup/disk/U disk/computer/electrical panel keyboard/battery, etc.

Our product contains: Small Character Ink Jet Printer, High Resolution Ink Jet Printer, Handheld Inkjet Printer, Big Character Ink Jet Printer, Laser Marking Machine, Vocuum Packing Machine, Carton Sealer, Shrink Packing Machine, Wrap Packing Machine, Strapping Machine, Automotic Labelling Machine and etc.

Technical Advantage

1 Adopted USA imported RF metal laser device, high performance, long service life, the cavity can always be used.

2 High accuracy and speed of engraving , the performance is extremely stable, support long time continuous work.

3 Excellent laser power utilization rate, and can be applied to a variety of nonmetal products in engraving and cutting.

4 Without consumables cost, clear marking, not easy to wear, high efficiency of engraving and cutting, environmental protection,energy saving.

5 DXF ,PLT, BMP ,AI ,JPG and other documents supported in the software, and can form the serial number, production date, bar code and planar bar code automatically . Support online flying, rotating marking, and support XY platform with large area partitioning marking.

Application Field

A. Materials: wood products, paper, cloth, leather, organic glass, acrylic, epoxy resin, unsaturated polyester resin and other non metal materials.

B. Industry: craft gift,furniture, leather and cloth, advertising signs, model products, food packaging,electronic components, pharmaceutical packaging, printing plate, nameplate, case and so on.
